DS-700
瀏覽人數:1885

產品說明



General Information
P/N: DS07-S000-00-1 Rated Power: 700W
Rated Wind Speed: 12 m/s Rated Speed: 405 rpm
Cut-In Wind Speed: <3 m Cut-Out Wind Speed: 15 m/s
Survival Wind Speed: 60 m/s
Dimension/Weight
Rotor Diameter: 1.93m Rotor Height: 1.6 m
Mast Height(Not Included): 3m (Min. recommended) Total Height: 4.6m (Min.)
Total Weight: 60 Kgs (Mast not included)
Rotor Specification
External Darrieus: 3 Blades
Internal Savonius: 2 Layers
Material of Blades: Anodized Aluminum
Material of Axis: Galvanized Steel SS400/Anodized Aluminum
Generator Specification
Generator Type: AC, 3 Phase, Synchronism PMG
Rated Output: 700W
Braking System
Automatic Braking: Over speed short circuit braking system
Manual Braking: 3-phase short circuit by NFB brake
Operation Environment
Ambient Temperature: -10~40°C
Ambient Humidity: 95% max.
Special Notes
  • Information and specification are subject to change without notice!
  • The information provided is based on the use of our standard 4m mast, please consult your local certified engineer if you are going to install with the mast higher than 3m.
  • Please follow your local regulations to install the DS-700 at proper location. Always consult your local certified civil engineer or structural engineer if you are planning to install the DS-700 on top of the roof.



DS-700 Wind Charge Controller

Model:

WD481000
Rated Output: 700 Watt
Max. Output: 1000 Watt
Input: 3 phase AC input
Voltage and Current range: Special design to meet DS-700 Wind Generator operation range
Power Control: With MPPT feature
Output: Charge to 48Vdc Battery Bank with minimum 200Ah capacity
  Max. charging current 20A
Protection Features: 1. Wind turbine over-speed protection
  2. Input over voltage protection
  3. Battery over charge protection
  4. Battery low voltage protection
  5. Over temperature protection
Power consumption: 1 Watt ( Standby Model )
LCD Display
Communication: RS-485 data port
Dimensions (L x W x H in mm): 200 x 142 x 50
Weight: 12 Kgs





DS-700 Power Curve and Dimension Figures
